46600 SERIES STAINLESS STEEL TRENCH DRAIN 12" WIDE WITH SS GRATING

Specification
Josam series 46600 fabricated stainless steel (type 304, 2mm THK), 12" wide, v-shaped bottom, available with or without slope (1% STD), with anchor tabs and leveling feet, bottom outlet and grate options. Run lengths longer than 13' provided with flanges and gaskets.

Options
-BWButt-Weld Outlet (avail 10,40,80) ===> P.O.A -VPSecured Grate
-FBFilter Basket -316Type 316L Material
-SBSediment Bucket TD.LENGTHTotal Run Length

Type # GRATE TYPE
46612 REINFORCED
46613 "
46614 "
46616 "
46618 "
46622 ANTI-SLIP MESH
46623 "
46624 "
46626 "
46628 "
46632 SOLID/PERIMETER
46633 "
46634 "
46636 "
46638 "
46642 LADDER
46643 "
46644 "
46646 "
46648 "
